電性數據Electrical Date
| 單晶Mono
|
JYG-027
|
| 額定峰值功率Nominal peak power(Pmax)
|
9.5
|
| 最大功率電壓Maximum Power Voltage(Vmp)
|
18
|
| 最大功率電流Maximum Power current(Imp)
|
0.53
|
| 短路電流Short-circuitcurrent(Isc)
|
0.59
|
| 開路電壓Open-cicuit Voltage(Voc)
|
21.6
|
| 電池片最優效率Optimized cell efficiency
|
16.5%-17%
|
工作范圍Limits
| 工作溫度Operating temperature
|
-40°C to +85°C
|
| 最大系統電壓Maximum system voltage
|
1000VDC
|
溫度系數Temperature and Coefficients
| NOCT
|
48°C+/-2°C
|
| 電流溫度系數Current temperature coefficient
|
%/K
|
0.06+/-0.01
|
| 電壓溫度系數Voltage temperature coefficient
|
mV/K
|
-(78+/-10)
|
| 功率溫度系數Power temperature coefficient
|
%/K
|
-(0.5+/-0.05)
|
其它數據Additional Data
| 電池片的數量和排列方式
Number of cells
and type of connection
|
|
| 尺寸Dimensions(MM)
|
L*W*H:200*300*2.5MM
|
| 凈重Weight(KG)
|
9.5W:160G
|
| 集裝箱裝載Container Loading
|
|
STC：AM1.5，1000W/㎡,working temperature ：25℃，
Humidity：＜80%，
Basic Cosmetic
Specification:
? Delaminations or bubbles do not form a continuous path
between any part of the electrical circuit and the edge
of module.
? Not any cracks, foreign materials or dirt of cells.
