品牌：RETZ/瑞茨我們一直致力于流體控制和測控領域的持續創新，始于2005……
淹沒式電磁脈沖閥亦稱亦稱嵌入閥，受脈沖控制儀輸出信號的控制，對濾袋逐排(室)噴吹清灰，使除塵器的阻力保持在設定的范圍之內，以保證除塵器的處理能力和收塵效率。它直接安裝在氣包上，具有更好的流通特性。壓力損失有所下降，適合于氣源壓力較低的工作場合。
RETZ
The submerged Electromagnetic pulse valve, also known as the embedded valve, is
controlled by the output signal of the pulse controller to spray the filter
bags row by row (room) to clean the dust, so as to keep the resistance of the
dust remover within the set range, so as to ensure the processing capacity and
dust collection efficiency of the dust remover. It is directly installed on the
air bag and has better flow characteristics. The pressure loss has decreased,
making it suitable for workplaces with low air supply pressure.
工作原理：
當接通壓縮空氣后，壓縮空氣通過節流孔進入后氣室，此時后氣室壓力將膜征緊貼閥的輸出口，電磁脈沖閥處于"關閉"狀態。
脈沖控制儀的電信號使沖閥銜鐵移動，閥后后室放氣孔打開，后氣室迅速失壓。膜片后移，壓縮空氣通過閥輸出口噴吹。脈沖處于“開啟”狀態。
進口淹沒式電磁脈沖閥材質說明/Material
Construction
閥體Body：ADC12鋁合金 ADC12 die cast
先導組件Armature：430FR不銹鋼等材料 430FR stainless
steel
膜片Diaphragm：丁晴橡膠或氟橡膠 Nitrile or Viton
彈簧Spring：321不銹鋼 321stainless
steel
緊固件Fasteners：302不銹鋼 302stainless
steel
進口淹沒式電磁脈沖閥技術參數Technical
Parameter
接口形式Joint
Form：淹沒Embedded
設計壓力Design
Pressure：0.2~0.8MPa
工作壓力Working
Pressure：0.2~0.6MPa
環境溫度Ambient
Temperature：常溫：-25~60℃低溫高溫可定制Customized for
Lower or Higher Temperature
相對濕度Relative
Humidity：≤85%
使用介質Working
Medium：清潔空氣Clean
Air
電壓Voltage：AC220VIAC110V/AC24V/DC24V/DC12V
Customized
防護等級Protection
Class：IP65
RETZ電磁脈沖閥是一種專為布袋式除塵器配套使用而設計的專用電磁閥，產品函蓋了直角式電磁脈沖閥、淹沒式電磁脈沖閥、直通式電磁脈沖閥、氣控脈沖閥、活塞式電磁脈沖閥、防爆系列脈沖閥等多種規格
